Full specification
Basic
| Name | Wild Dragon Carbon Wheelset |
|---|---|
| Type | Fat Bike |
| Size | 26" or 27.5" |
| Brake Interface | Disc Brake (6-Bolt) |
| Edition | Premium Edition |
| ASTM Classification | Condition 5 |
| Warranty | 3 Years |
Dimensions
| Rims | Carbon Fiber Wild Dragon III |
|---|---|
| Holes | 32 front / 32 rear |
| Nipples | SAPIM Secure Lock |
| Weight | 26" from 1925g | 27.5" from 2015g |
| Valve Hole Diameter | 6.5mm (Presta) |
| Spokes | Sapim. DT Swiss. Pillar. |
| Drain Holes | No |
| Tubeless Compatible | Yes |
| Tubeless Ready | Optional |
| Hubs | DT Swiss 350SL Big Ride |
Recommendation
| Tire Size | 4.0" ~ 5.2" |
|---|---|
| Tire Pressure | 5 ~ 15psi |
| Spoke Tension | 110 ~ 130kgf |
| Max System Weight | 250Kg |
| Ideal Valve Stem Length | 44mm |
Discipline
| Discipline | Trail. Dirt. Enduro. Snow. Sand. Bogs. Desert. Mud |
|---|
About Tubeless Ready
| Lighter | Since no tubeless tape wrapping on the Tubeless Ready wheels, the weight of Tubeless Ready wheel goes lighter than the weight of common wheel with tape wrapped; |
|---|---|
| Stronger | No holes drilling on rim bed (except valve holes) and the carbon fibers not being damaged, the rim bed would be kept integral and the strength increases; |
| Safe | Tubeless Ready wheels no risk of air leaking from the rim bed, the cycling stays safe and the journey could be longer than riding bike with common wheels. |
| Disadvantage | Needs professional maintaince in case of spoke breaking |
Best Features
- 1. Extra Wide Options Fit Jumbo Snow Tires for Extreme Snow Conditions while Reducing Rotating Mass.
- 2. Wide 90mm Design is Ideal for Four-season Trail Riding with 4.0" to 5.2" Wide Tires.
- 3. The 40mm Deep Section of the Wild Dragon Rims Provides Extra Rigidity for More Aggressive Riders.
- 4. Providing a Deep Channel between the Bead Seats Makes It Easier to Install and Take Off Tires.
- 5. A Compact Bead Socket Locks Tires in Tightly for Easy Tubeless Installation.
- 6. Aero-style Rim Profile (the triangle-like shape) Sheds Dirt and Mud when Conditions Get Rough.
About this product
The details
Introduction
NEXTIE offers a full line of custom bike rims for Fat Bike wheels, providing tailor-made solutions to meet your specifications. We have years of experience in wheel-building, and we cater to the needs of each customer. In our inventory, we offer different sizes carbon fiber fat bike rims.
At NEXTIE, we build each wheel with precision and care, you can be confident that you are getting a high quality custom bicycle wheelset when you buy from us.
If you are interested in customzing your bike with new and stylish rims, the experts at NEXTIE are ready to make your bike look great and improve your preformance on the trails. We have been serving the cycling community since 2013, and all our custom bike rims are made here in China.
Wheelset Weight Reference
1925g: Wild Dragon III 90 (26" 90mm) Rims + DT350 Big Ride Hubs + Sapim CX-Ray Spokes + Sapim Alloy Nipples)
2015g: Wild Dragon III 90-27 (27.5" 90mm) Rims + DT350 Big Ride Hubs + Sapim CX-Ray Spokes + Sapim Alloy Nipples)
Carbon Fat Bike Rims (Double Wall)
Wild Dragon III 90 (26" 90mm): 560g
Wild Dragon III 90-27 (27.5" 90mm): 600g
Hubs
DT Swiss 350 Big Ride: 15x150mm / 12x197mm. Rachet 36T. 6-Bolt. 32Holes.
Hub Body: Shimano MTB. Sram XD. Shimano Micro Spline 12S,
Weight: 212g front 307g rear.
Spokes
Spokes Sapim CX-Ray (64 pcs x 260 mm lg) 272g
Spokes Sapim D-Light 2.0/1.65 (64 pcs x 260 mm lg) 307g
Spokes DT Competition 2.0/1.8 (64pcs x 264mm lg) 382g
Spokes DT Competition Race 2.0/1.6 (64pcs x 264mm lg) 312g
Spokes Pillar X-Tra 1420 (64pcs x 260mm lg) 275g;
Nipples
Sapim Polyas Secure Lock, DT Swiss Prolock, Alloy / Brass in color black, red, orange, gold, blue, green, purple, pink, silver and more.
What's in the Box
Carbon Wheelset (Front + Rear)
2 x Extra Spokes
2 x Tubeless Valve Stems
1 x Tubeless Tape
Learn more
What is the difference between weaves UD, 3K and 12K?
What is Free Coating Manufacturing (FCM) process?
What is the Difference between Ultralight, Premium and Standard Edition?
What is ERD (Effective Rim Diameter)?
How much spoke tension should I use?
Photos
More >>
Nextie · Fat wheelsets
Nextie Wild Dragon carbon fat bike wheelset (90 mm, 26" or 27.5")
£1,221
Inc. VAT · UK delivery calculated at checkout · free UK delivery over £200
We don't hold this in stock. As an authorised Nextie distributor we order it in for you when you buy — usually about 6 weeks. We'll email you when it ships.
£1,221
Ordered in for you: About 6 weeks. We email you when it arrives. Pay 50% now, and the other 50% when it's ready to send.
- ✓ Free UK delivery over £200, or collect from the workshop
- ✓ 14-day returns on online orders
- ✓ Secure payment: card, Apple Pay, Google Pay or PayPal
Secure checkout by Stripe — card, Apple Pay, Google Pay or PayPal. We never see your card details. Returns and cancellations.
Details
Complete carbon wheelset built by Nextie in their factory, from 1925 g. Choose your rim finish, hubs, spokes and freehub. Ordered in for you from Nextie.
