Bespoke titanium frame
A titanium road race frame, made to fit
Seven sizes from 47 to 61 cm as the starting point, then every number set to suit you.
From £1,999
Includes VAT and free UK delivery. About 12 weeks from drawing approval.
- Sizes
- XXS to XXL
- Wheels
- 700c
- Tyres
- 25 mm to 34 mm
- Warranty
- 5 years
A race frame is about position: a low, long reach you can hold for hours, a steady front end and quick handling. Because the angles and stem length change from size to size, a small frame is a different shape to a large one. The road race sizes follow a full geometry chart, so each size has its own head angle, seat angle and stack.
Start from the size nearest you, then change what you like. The drawing is to scale and warns you if tyre, chainring or heel clearance gets tight. Titanium gives a smooth ride that lasts, and the frame takes disc brakes and a thru axle.
What you can choose
- Sizes
- XXS (47 cm) to XXL (61 cm), seven in all, each with its own angles and stem length as the starting point.
- Tyres
- From 25 to 34 mm. The standard is 28 mm.
- Brakes and axle
- Flat mount disc brakes and a 12 x 142 mm thru axle, with a 68 mm or 73 mm English-threaded bottom bracket.
- Mounts and routing
- Rack and mudguard mounts, bottle bosses and internal cable routing are free. Add a titanium nitride finish for £399.
See the standard geometry of every size
| Size | Reach | Stack | Head angle | Seat angle | Chainstay | BB drop | Seat tube |
|---|---|---|---|---|---|---|---|
| XXS47 cm, 380 mm bars | 380 | 505 | 70.5° | 74.5° | 412 | 70 | 450.8 |
| XS49 cm, 380 mm bars | 388 | 511 | 71° | 74.5° | 412 | 70 | 480.9 |
| S52 cm, 380 mm bars | 389 | 527 | 72° | 74° | 412 | 70 | 501.4 |
| M54 cm, 400 mm bars | 389 | 548 | 72.5° | 73.6° | 412 | 70 | 521.6 |
| L56 cm, 400 mm bars | 394.5 | 568 | 73° | 73.3° | 412 | 70 | 541.4 |
| XL58 cm, 400 mm bars | 400 | 589 | 73.3° | 73° | 412 | 70 | 558.8 |
| XXL61 cm, 420 mm bars | 409 | 606 | 73.3° | 72.5° | 412 | 70 | 571.4 |
Millimetres unless shown. Seat tube is bottom bracket centre to top tube centre. Every number can be changed in the designer, within limits that keep the frame sound. How to choose a size
On every frame
- Material: Ti-3Al-2.5V titanium, brushed finish
- Head tube: Engraved with the Travers logo
- Down tube: Travers logo bead-blasted on the underside
- Rear axle: 12 x 142 mm thru axle
- Seat tube: 31.8 mm, takes a 27.2 mm seatpost
- Brakes: Flat mount disc, 160 mm rotor
- Mounts: Bottle cage mounts on the down tube and seat tube
Made to order in titanium, then inspected, checked and cleaned by me before it reaches you. Covered by my 5-year frame warranty. Why titanium?
Options and prices
Rack, mudguard and bag mounts, extra bottle bosses and internal routing are free.
See every option and price
| Titanium nitride finish | +£399 |
|---|---|
| Pinion gearbox frame | +£350 |
| Sliding dropouts | +£20 |
| Belt-drive splitter | +£10 |
| Couplers (travel frame) | Ask |
| Extra bottle bosses | Free |
| Rack and mudguard mounts | Free |
| Internal cable routing | Free |
| Post mount brake (instead of flat mount) | Free |
| Dropper post routing | Free |
| Top tube bag mounts | Free |
Questions
What sizes does the road race frame come in?
XXS (47 cm), XS (49), S (52), M (54), L (56), XL (58) and XXL (61). Each is a starting point, and every number can be changed.
How is it different from the endurance frame?
The race frame is lower and longer at the front. A size 56 has a stack of 568 mm, against 599 mm on the endurance frame, and a slightly steeper head angle and shorter chainstays.
Can I use mudguards?
Yes. Rack and mudguard mounts are a free option, though a race frame is designed for tyres up to 34 mm, so check the clearance for your mudguards in the designer.
