Bespoke titanium frame
A titanium fat bike frame, made for you
26-inch wheels, tyres up to 5 inches, and the choice of chain, belt drive or a Pinion gearbox.
From £2,199
Includes VAT and free UK delivery. About 12 weeks from drawing approval.
- Sizes
- Small to XXL
- Wheels
- 26"
- Tyres
- 3.8" to 5.0"
- Warranty
- 5 years
Fat bikes are for floating over sand, snow and mud on big, comfortable tyres. The frame has to make room for them: wide stays, a wide bottom bracket and a long enough chainstay to keep the tyre clear of everything. A titanium frame suits the job well, and it keeps its looks through winter.
Start from my standard fat bike frame and change what you like. The designer checks the tyre, chainring and heel clearance against the wide stays, and shows the wheelbase and bottom bracket height.
What you can choose
- Tyres
- From 3.8 to 5.0 inch tyres on 26-inch wheels.
- Spacing and bottom bracket
- 12 x 197 mm rear spacing and a 120 mm English-threaded bottom bracket.
- Belt drive and gearboxes
- Add a Pinion gearbox frame (+£350), a belt-drive splitter (£10) or sliding dropouts (£20).
- Mounts and details
- Bottle bosses, rack and mudguard mounts and internal routing are free, and the Travers logo is engraved on the head tube.
See the standard geometry of every size
| Size | Reach | Stack | Head angle | Seat angle | Chainstay | BB drop | Seat tube |
|---|---|---|---|---|---|---|---|
| Small | 420 | 603.4 | 70° | 72° | 445 | 60 | 430 |
| Medium | 445 | 603.4 | 70° | 72° | 445 | 60 | 460 |
| Large | 469.5 | 617.5 | 70° | 72° | 445 | 60 | 500 |
| XL | 494 | 631.6 | 70° | 72° | 445 | 60 | 550 |
| XXL | 518 | 645.7 | 70° | 72° | 445 | 60 | 610 |
Millimetres unless shown. Seat tube is bottom bracket centre to top tube centre. Every number can be changed in the designer, within limits that keep the frame sound. How to choose a size
On every frame
- Material: Ti-3Al-2.5V titanium, brushed finish
- Head tube: Engraved with the Travers logo
- Down tube: Travers logo bead-blasted on the underside
- Rear axle: 12 x 197 mm fat bike spacing
- Seat tube: 34.9 mm, takes a 31.6 mm seatpost
- Brakes: Disc, 160 mm rotor
- Mounts: Bottle cage mounts on the down tube and seat tube
Made to order in titanium, then inspected, checked and cleaned by me before it reaches you. Covered by my 5-year frame warranty. Why titanium?
Options and prices
Rack, mudguard and bag mounts, extra bottle bosses and internal routing are free.
See every option and price
| Titanium nitride finish | +£399 |
|---|---|
| Pinion gearbox frame | +£350 |
| Sliding dropouts | +£20 |
| Belt-drive splitter | +£10 |
| Couplers (travel frame) | Ask |
| Extra bottle bosses | Free |
| Rack and mudguard mounts | Free |
| Internal cable routing | Free |
| Post mount brake (instead of flat mount) | Free |
| Dropper post routing | Free |
| Top tube bag mounts | Free |
Questions
What is the biggest tyre it takes?
The frame is drawn for tyres up to 5.0 inches. The designer shows the gaps for the tyre you choose and warns you if a chainring would not clear.
Can I run a belt drive or a Pinion gearbox?
Yes. A Pinion frame is +£350 and a belt-drive splitter is £10. Sliding dropouts, for single speed or hub gears, are £20.
What rear hub spacing does it use?
12 x 197 mm, the usual fat bike spacing.
Other bespoke frames
Ready to design yours?
It takes a few minutes and it's free to ask. I check everything before I quote.
