Bespoke titanium frame
A titanium gravel frame drawn around you
700c wheels, room for tyres up to 50 mm, drop bars, and every measurement set to suit how you ride.
From £1,999
Includes VAT and free UK delivery. About 12 weeks from drawing approval.
- Sizes
- Small to XXL
- Wheels
- 700c
- Tyres
- 32 mm to 50 mm
- Warranty
- 5 years
A gravel bike has to do a lot: fast road links, rough tracks, a loaded weekend away. So the fit matters more than on most bikes. With a bespoke titanium frame you choose the reach and stack to suit your body and the bars you ride, instead of settling for the nearest size.
Start from my standard gravel frame, pick your size, then change what you like: top tube, head tube length, chainstay length for tyre room, BB drop, bottom bracket and mounts. The drawing updates to scale and warns you if a tyre would touch the frame.
What you can choose
- Tyre room
- From 32 mm up to 50 mm tyres. Tell me the biggest you might ever want and I will draw in the clearance.
- Mounts for the way you ride
- Rack and mudguard mounts, top tube bag mounts and extra bottle bosses are all free. Internal cable routing is free too.
- Brakes and axle
- Flat mount disc brakes and a 12 x 142 mm thru axle as standard, with a post mount brake available at no charge.
- Finish and details
- Brushed titanium with the Travers logo engraved on the head tube. Add a titanium nitride finish for £399.
See the standard geometry of every size
| Size | Reach | Stack | Head angle | Seat angle | Chainstay | BB drop | Seat tube |
|---|---|---|---|---|---|---|---|
| Small50 cm | 364.5 | 543.9 | 72.5° | 73.5° | 425 | 64 | 495 |
| Medium53 cm | 378.5 | 562.9 | 72.5° | 73.5° | 425 | 64 | 525 |
| Large56 cm | 393 | 582 | 72.5° | 73.5° | 425 | 64 | 555 |
| XL59 cm | 407.5 | 601.1 | 72.5° | 73.5° | 425 | 64 | 585 |
| XXL62 cm | 421.5 | 620.1 | 72.5° | 73.5° | 425 | 64 | 615 |
Millimetres unless shown. Seat tube is bottom bracket centre to top tube centre. Every number can be changed in the designer, within limits that keep the frame sound. How to choose a size
On every frame
- Material: Ti-3Al-2.5V titanium, brushed finish
- Head tube: Engraved with the Travers logo
- Down tube: Travers logo bead-blasted on the underside
- Rear axle: 12 x 142 mm thru axle
- Seat tube: 31.8 mm, takes a 27.2 mm seatpost
- Brakes: Flat mount disc, 160 mm rotor
- Mounts: Bottle cage mounts on the down tube and seat tube
Made to order in titanium, then inspected, checked and cleaned by me before it reaches you. Covered by my 5-year frame warranty. Why titanium?
Options and prices
Rack, mudguard and bag mounts, extra bottle bosses and internal routing are free.
See every option and price
| Titanium nitride finish | +£399 |
|---|---|
| Pinion gearbox frame | +£350 |
| Sliding dropouts | +£20 |
| Belt-drive splitter | +£10 |
| Couplers (travel frame) | Ask |
| Extra bottle bosses | Free |
| Rack and mudguard mounts | Free |
| Internal cable routing | Free |
| Post mount brake (instead of flat mount) | Free |
| Dropper post routing | Free |
| Top tube bag mounts | Free |
Questions
What size tyres will a titanium gravel frame take?
My standard gravel frame is designed for 700c tyres from 32 mm up to 50 mm. The designer shows the clearance around the tyre you choose, and warns you if it gets tight.
Can I fit mudguards and a rack?
Yes. Rack and mudguard mounts are a free option, along with top tube bag mounts and extra bottle bosses.
How do I know which size to choose?
Sizes run from Small (50 cm) to XXL (62 cm). The Find my size tab turns your height and inside leg into a starting point, and the Compare my bike tab draws your current bike over the new frame. The sizing guide explains what to measure.
Other bespoke frames
Ready to design yours?
It takes a few minutes and it's free to ask. I check everything before I quote.
