From the maker
Full specification
Basic
| Code | NXT40CGX-6S |
|---|---|
| Rim Type | Clincher (Hookless) |
| Materials | Toray T700 + T800 Carbon Fiber |
| Warranty | 3 Years |
| Release Time | May 2022 |
Dimensions
| Size | 700C |
|---|---|
| External Wide | 31mm |
| Internal Width | 25mm |
| Rim Height | 40mm |
| Rim Lip Thickness | 3.0mm |
| Weight | 720g Front / 800g Rear (Upgrade 2024) |
| Valve Hole Diameter | 6.5mm (Presta) |
| Drain Holes | No (leave a note if you prefer Drain Holes) |
Appearance
| Carbon Weave | UD |
|---|---|
| Finish | Matte / Glossy / Free Coating |
Recommendation
| Tire Size | 33 ~ 50mm Road / 33 ~ 40mm Cyclocross / 33 ~ 62mm Gravel |
|---|---|
| Tire Pressure | 29 ~ 61psi Road / 24 ~ 39psi Cyclocross / 22 ~ 58psi Gravel |
| Max System Weight | 144Kg |
Discipline
| Discipline | Road, Gravel, Cyclocross |
|---|
About this product
The details
Introduction
Over the years, NEXTIE has been committed to making the best carbon fiber bicycle wheels, especially the continuous improvement of gravel wheels, which has been recognized and favored by many fan customers from all over the world. There have been constant suggestions from customers whether we could develop an Integrated gravel wheelset. We love to listen to riders and develop the products they love. After months of research, development and testing, now we release the gravel wheelset NXT40CGX-6S. The weight of the wheels (front + rear) is 1520g (Upgrade 2024).
The spokes of the 6-spoke wheelset are all aerodynamically designed, which can effectively break the wind and reduce the riding resistance when riding. The wheels can all be equipped with DT350 or DT240 hubs. Especially, the 6-spoke wheelset can be equipped with our newly developed self-owned brand hub Rollingstar. For more information about Rollingstar hubs, you may view this page: Rollingstar-II-Hubs
The tire size for this model of rim is recommended at 33 ~ 50mm Road / 33 ~ 40mm Cyclocross / 33 ~ 62mm Gravel. The tire pressure is recommended at 29 ~ 61psi Road / 24 ~ 39psi Cyclocross / 22 ~ 58psi Gravel.
What's in the Box
Front & Rear Complete Wheels
2 x Tubeless Valve Stem
Learn more
What is the difference between weaves UD, 3K and 12K?
What is Free Coating Manufacturing (FCM) process?
What is the Difference between Ultralight, Premium and Standard Edition?
What is ERD (Effective Rim Diameter)?
How much spoke tension should I use?
Nextie · Gravel wheelsets
Nextie six-spoke carbon gravel wheelset 700c
£1,429
Inc. VAT · UK delivery calculated at checkout · free UK delivery over £200
We don't hold this in stock. As an authorised Nextie distributor we order it in for you when you buy — usually about 6 weeks. We'll email you when it ships.
£1,429
Ordered in for you: About 6 weeks. We email you when it arrives. Pay 50% now, and the other 50% when it's ready to send.
- ✓ Free UK delivery over £200, or collect from the workshop
- ✓ 14-day returns on online orders
- ✓ Secure payment: card, Apple Pay, Google Pay or PayPal
Secure checkout by Stripe — card, Apple Pay, Google Pay or PayPal. We never see your card details. Returns and cancellations.
Details
Complete carbon wheelset built by Nextie in their factory, 1520 g. Choose your rim finish, hubs, spokes and freehub. Ordered in for you from Nextie.
