Nextie #01 carbon road handlebar
£228
Inc. VAT · UK delivery from £8 · free UK delivery over £200
I don't hold this in stock. As an authorised Nextie distributor I order it in for you when you buy, usually about 6 weeks. I'll email you when it ships.
- ✓ Free UK delivery over £200, or collect from the workshop
- ✓ Ordered in or built for you, so it can't be cancelled once I've ordered it. Faulty or not as described: full refund
- ✓ Secure payment: card, Apple Pay, Google Pay or PayPal
Secure checkout by Stripe: card, Apple Pay, Google Pay or PayPal. I never see your card details. Returns and cancellations.
5.0 from 17 Google reviews · an independent workshop in Rochford since 2012
- “Great service & highly recommended. Many thanks.” – Robert, September 2026
Sold by Michael at Travers Bikes, Canewdon, Essex: I answer questions myself. Warranty · Ask about this part
Details
A classic integrated carbon handlebar for road bikes, made from Toray T700 carbon. The bar and stem are one piece, so there is nothing to clamp at the stem.
Bar width: 430mm
Stem length: 90mm or 110mm
Steerer diameter: 28.6mm
Reach: 77mm
Drop: 142mm
Weight: from 310g (90mm x 430mm)
Finish: matte UD carbon
Want it fitted? Book it into the workshop.
From the maker
Full specification
Basic
| Code | NXTHB01 |
|---|---|
| Materials | Carbon Fiber |
Dimensions
| Bar Length | 430mm |
|---|---|
| Stem Length | 90mm / 110mm |
| Steer Diameter | 28.6mm |
| Weight | 310g (90mm x 430mm) |
| Reach | 77mm |
| Drop | 142mm |
| Angle | 73° |
Appearance
| Carbon Weave | UD |
|---|---|
| Finish | Matte |
Discipline
| Discipline | Road |
|---|
About this product
The details
Introduction
This carbon fiber handlebar is a classic integrated handlebar for road bicycle, with a stem length of 90mm and 110mm, bar length of 430mm. The weight is from 310g. The body is made up of carbon fibers and the bolts are materials of alluminium alloy.
Design Features
High quality toray T700 carbon fiber material;
Superior fatigue and impact strength.
What's in the Box
Carbon handlebar
Reviews
Bought this? Be the first to tell other riders what you think.
